Advantages:
1.The machine is made of stainless steel.
2.Work continuity, machine reasonable design, compact cohesion, midway don't need to stop.
3.Work efficiency, increase the air pressure tank, powerful, oil processing speed is fast.
4.Product effect is good, oil clear and bright, no phosphorus precipitation, the pot doesn't foam.
5.Simple and convenient operation, button only after operation, no cumbersome manual operation.
Main date
| No | Serial number | Equipment name | Quantity | Power(KW) | Materials | Remark |
| 1 | L101A/B | Refining tank | 2 | 0.55×2 | SS304 | Diameter: 900mm; Straight section height: 1000mm; Lower cone head, cone angle: 90°; Steel plate thickness: 3mm |
| 2 | L102 | Hot water, alkaline water tank | 1 | SS304 | Steel plate thickness: 3mm | |
| 3 | L103 | Clay box | 1 | SS304 | Steel plate thickness: 3mm. | |
| 4 | L104 | Decolorization tank | 1 | 0.55 | SS304 | Diameter: 900mm; Straight section height: 1000mm; Upper elliptical head; Lower cone head, cone angle: 90°; Steel plate thickness: 6mm. |
| 5 | L105 | Leaf filter | 1 | SS304 | Diameter: 350mm; Height of straight section: 500mm; Filtering area: 2M2 Steel plate thickness: 5mm 3 eyepieces |
|
| 6 | L106 | Bag filter | 1 | SS304 | Steel plate thickness: 4mm 4 filter bags |
|
| 7 | L107 | Deodorant tank | 1 | 12 | SS304 | Diameter: 900mm; Straight section height: 1000mm; The upper and lower parts are all oval heads; Steel plate thickness: 6mm. With steam heating coil + electric heating. Diameter 800mm |
| 8 | L108 | Gas collection device | 1 | SS304 | Steel plate thickness: 4mm | |
| 9 | L109 | Water ring vacuum pump | 1 | 4 | ||
| 10 | L110 | Water tank | 1 | SS304 | Steel plate thickness:3mm | |
| 11 | L111 | Steam superheater | 1 | Pressure vessel | ||
| 12 | L112 | Electric heating heat conduction oil furnace | 1 | 18 | SS304 | Main engine, high oil tank, position oil tank, heat transfer oil circulating pump |
| 13 | L113 | Air compressor | 1 | 5.5 | Users configure their own. | |
| 14 | P101 | Saponin Oil Pump | 1 | 2.2 | ||
| 15 | P102 | Decolorization pump | 1 | 1.1 | SS304 | |
| 16 | P103 | Oil pump | 1 | 1.1 | SS304 | |
| 15 | Distribution Cabinet | 1 | ||||
| 16 | Installation material | Pipes, valves, fittings and other materials are all SS304 | ||||
| 17 | Total | 18 | 45.55 |
More photos
